LA-CQ01-PR-200K-A
LA-CQ01-PR-200K-A，Wavelength range：900-1700 nm，3dB bandwidth：DC-200 KHz，Photosensitive surface：75 um，Gain：5×10^6 V/W，NEP：4.5 pw∕Hz^1∕2，Saturation power：-30dBm
|
|
4-6week |
$640.69 |
|
|
|
|
LA-CQ01-PR-200K-B
LA-CQ01-PR-200K-B,Wavelength range：320-1000nm，3dB bandwidth：DC-200 KHz，Photosensitive surface：1.2mm，Gain：2.5×10^6 V/W，NEP： 9pw∕Hz^1∕2，Saturation power：-27dBm
|
|
4-6week |
$640.69 |
|
|
|
|
LA-CQ01-PR-10M-A
LA-CQ01-PR-10M-A,Wavelength range：900-1700 nm，3dB bandwidth：DC-10MHz，Photosensitive surface：75um，Gain：2×10^5 V/W，NEP：11 pw∕Hz^1∕2，Saturation power：-15dBm
|
|
4-6week |
$640.69 |
|
|
|
|
LA-CQ01-PR-10M-B
LA-CQ01-PR-10M-B，Wavelength range：320-1000 nm，3dB bandwidth：DC-10MHz，Photosensitive surface：1.2mm，Gain：1×10^5 V/W，NEP：22 pw∕Hz^1∕2，Saturation power：-12dBm
|
|
4-6week |
$640.69 |
|
|
|
|
LA-CQ01-PR-200M-A
LA-CQ01-PR-200M-A，Wavelength range：900-1700 nm，3dB bandwidth：DC-200 MHz，Photosensitive surface：75um，Gain：1.8×10^4 V/W，NEP：14 pw∕Hz^1∕2，Saturation power：-8dBm
|
|
4-6week |
$720.78 |
|
|
|
|
LA-CQ01-PR-200M-B
LA-CQ01-PR-200M-B，Wavelength range：320-1000 nm，3dB bandwidth：DC-200 MHz，Photosensitive surface：800um，Gain：9×10^3 V/W，NEP：28 pw∕Hz^1∕2，Saturation power：-5dBm
|
|
4-6week |
$720.78 |
|
|
|
|
LA-CQ01-PR-500M-A
LA-CQ01-PR-500M-A，Wavelength range：900-1700 nm，3dB bandwidth：DC-500 MHz，Photosensitive surface：75um，Gain：1.5×10^3 V/W，NEP：6 pw∕Hz^1∕2，Saturation power：0dBm
|
|
4-6week |
$800.86 |
|
|
|
|
LA-CQ01-PR-500M-B
LA-CQ01-PR-500M-B，Wavelength range：320-1000 nm，3dB bandwidth：DC-500 MHz，Photosensitive surface：400 um，Gain：0.8×10^3 V/W，NEP：11.2 pw∕Hz^1∕2，Saturation power：3dBm
|
|
4-6week |
$800.86 |
|
|
|
|
LA-CQ01-PR-1G-A
LA-CQ01-PR-1G-A，Wavelength range：900-1700 nm，3dB bandwidth：50K-1 GHz，Photosensitive surface：75 um，Gain：1×10^3 V/W，NEP：50 pw∕Hz^1∕2，Saturation power：2dBm
|
|
4-6week |
$961.04 |
|
|
|
|
LA-CQ01-PR-1G-B
LA-CQ01-PR-1G-B，Wavelength range：320-1000 nm，3dB bandwidth：50K-1 GHz，Photosensitive surface：400 um，Gain：500 V/W，NEP：100 pw∕Hz^1∕2，Saturation power：5dBm
|
|
4-6week |
$961.04 |
|
|
|
|
LA-CQ01-PR-2G-A
LA-CQ01-PR-2G-A，Wavelength range：800-1700 nm，3dB bandwidth：50K-2 GHz，Photosensitive surface：75 um Gain：1×10^3 V/W，NEP：50 pw∕Hz^1∕2，Saturation power：2dBm
|
|
4-6week |
$1121.21 |
|
|
|
|
LA-CQ01-PR-2G-B
LA-CQ01-PR-2G-B，Wavelength range：400-1100 nm，3dB bandwidth：50K-2 GHz，Photosensitive surface：150 um，Gain：200 V/W，NEP：250 pw∕Hz^1∕2，Saturation power：5dBm
|
|
4-6week |
$1121.21 |
|
|
|
 |
ST-PDAVG-Si2
Wavelength:300-1060 nm;Peak Responsivity: 0.57A/W @800 nm;Effective Area:D = 0.8*0.8 mm, Rise Time:2ns-250us;Bandwidth:200 MHz-1.52 kHz;Gain at 50 Ω Load:19.08 V/A-10 MV/A;Noise-Equivalent Power (NEP) (pW/√Hz):47.12-8.34;Output Voltage:0~-4 V
|
|
Contact us |
Request for quote |
|
|
|
|
ST-PDA150000-Si2
Wavelength:300-1060 nm nm;Peak Responsivity: 0.57A/W @ 800 nm;Effective Area:D = 0.8mm, S = 0.5 mm^2;Rise Time:2.3ns;Bandwidth:150MHz;Gain at 50 Ω Load:0.1 kV/A;Noise-Equivalent Power (NEP) (pW/√Hz):23.6;Output Voltage:0~-4 V
|
|
Contact us |
Request for quote |
|
|
|
|
ST-PDA020000-Si2
Wavelength:300-1060 nm nm;Peak Responsivity: 0.57A/W @800 nm;Effective Area:D =0.8 mm, S = 0.5 mm^2;Rise Time:18ns;Bandwidth:21.2MHz;Gain at 50 Ω Load:0.72 kV/A;Noise-Equivalent Power (NEP) (pW/√Hz):7.9;Output Voltage:0~-4 V
|
|
Contact us |
Request for quote |
|
|
|
|
ST-PDA002000-Si2
Wavelength:300-1060 nm0 nm;Peak Responsivity: 0.57A/W @ 800 nm;Effective Area:D = 0.8 mm, S = 0.5 mm^2;Rise Time:145ns;Bandwidth:2.61MHz;Gain at 50 Ω Load:5.85 kV/A;Noise-Equivalent Power (NEP) (pW/√Hz):8.71;Output Voltage:0~-4 V
|
|
Contact us |
Request for quote |
|
|
|
|
ST-PDA000200-Si2
Wavelength:300-1060 nm nm;Peak Responsivity: 0.57A/W @ 800 nm;Effective Area:D = 0.8 mm, S = 0.5 mm^2;Rise Time:1.4us;Bandwidth:271KHz;Gain at 50 Ω Load:56.3 kV/A;Noise-Equivalent Power (NEP) (pW/√Hz):7.87;Output Voltage:0~-4 V
|
|
Contact us |
Request for quote |
|
|
|
|
ST-PDAVG-InGaAs0
Wavelength:800-1700 nm;Peak Responsivity:1.10A/W @ 1550 nm;Effective Area:D = 1 mm, S = 0.5 mm^2;Rise Time:2ns-250us;Bandwidth:200 MHz-1.52 kHz;Gain at 50 Ω Load:19.08 V/A-10 MV/A;Noise-Equivalent Power (NEP) (pW/√Hz):47.12-8.34;Output Voltage:0~-4V
|
|
Contact us |
Request for quote |
|
|
|
|
ST-PDA150000-InGaAs0
Wavelength:800-1700 nm;Peak Responsivity:1.10A/W @ 1550 nm;Effective Area:D = 1 mm, S = 0.5 mm^2;Rise Time:2.3 ns;Bandwidth:150 MHz;Gain at 50 Ω Load:0.1 kV/A;Noise-Equivalent Power (NEP) (pW/√Hz):23.6;Output Voltage:0~-4 V
|
|
Contact us |
Request for quote |
|
|
|
|
ST-PDA020000-InGaAs0
Wavelength:800-1700 nm;Peak Responsivity:1.10A/W @ 1550 nm;Effective Area:D = 1 mm, S = 0.5 mm^2;Rise Time:18 ns;Bandwidth:21.2 MHz;Gain at 50 Ω Load:0.72 kV/A;Noise-Equivalent Power (NEP) (pW/√Hz):7.9;Output Voltage:0~-4 V
|
|
Contact us |
Request for quote |
|
|
|
|
ST-PDA002000-InGaAs0
Wavelength:800-1700 nm;Peak Responsivity:1.10A/W @ 1550 nm;Effective Area:D = 1 mm, S = 0.5 mm^2;Rise Time:145 ns;Bandwidth:2.61MHz;Gain at 50 Ω Load:5.85 kV/A;Noise-Equivalent Power (NEP) (pW/√Hz):8.71;Output Voltage:0~-4 V
|
|
Contact us |
Request for quote |
|
|
|
|
ST-PDA000200-InGaAs0
Wavelength:800-1700 nm;Peak Responsivity:1.10A/W @ 1550 nm;Effective Area:D = 1 mm, S = 0.5 mm^2;Rise Time:1.4us;Bandwidth:271KHz;Gain at 50 Ω Load:56.3 kV/A;Noise-Equivalent Power (NEP) (pW/√Hz):7.87;Output Voltage:0~-4 V
|
|
Contact us |
Request for quote |
|
